SP100-4PB0-DH 무보충형 ORP센서

제 품 특 징



· 모델명: SP100-4PB0-DH

· 무보충형 ORP 센서

· 측정 범위: ± 5000 mV

· 측정 온도: 0 ~ 80ºC

· Epoxy

· 최대압력: 4 bar





구 성 내 역

· SP100-4PB0-DH   1EA

   케이블 별도



전 극 사 양

품명	ProcessProbe™ Sensors with PG13.5 Threads
모델	SP100-4PB0-DH	SP200-2PB0-DH
ORP Tip	Glass with Platinum band
Reference	Silver/Silver Chloride (Ag/AgCl)
Reference Junction	Precision made junction of specially formulated low porosity ceramic
Electrolyte	3.8 Molar Potassium Chloride (KCl) Gel
Redox Range	±5000 mV
Temperature Range SP100 Series	Operation: 0 ~ 80ºC	-5 ~ 110ºC
Max Pressure SP100 Series	4 bar (atm), 58 psig	10 bar (atm), 150 psig
Connector	Standard Pg13.5 threaded cap with -S8 cable attachment. O-ring sealed
Wetted Materials SP100 Series	Glass, Ceramic, Epoxy, Silicone	Glass, Ceramic
